| Rated zero-power resistance R25 |
10.0Kohm |
Zero-power resistance is measured at 25°C |
| Tolerance of rated zero-power resistance R25 |
±1% |
- |
| Rated B-value B25/85 |
3435K |
B-value is calculated with the zero-power resistance values measured at 25°C and 85°C |
| Tolerance of rated B-value B25/85 |
±1% |
- |
| Hi-pot tes |
AC 2000V/1 Sec |
Shall be withstand between each end of sensor and the shell |
| Thermal time constant |
About 35 Sec |
In 25°C to 85°C air |
| Dissipation constant |
Min 4mW/°C |
In still air |
| Operating temperature range |
-25°C~+70°C |
- |
| Waterproof level |
IP68 |
- |
